Special Valve Machining Machine - Two Side Porous Drill Valve Body - Valve Drilling Machine

Brand Name:	Vicord
Model Number:	YC II Z200/300/400/600HT
MOQ:	1
Price:	Negotiable
Payment Terms:	L/C,T/T
Supply Ability:	30 set per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Maximum Drilling Center Distance (mm):

295-770

Maximum Machining Length(mm):

600-1000 Mm

Minimum Machining Length(mm):

200-300 Mm

Surface Roughness:

12.5

Spindle Motor Range (r/min):

225/286

Control System:

PLC

Warranty:

1 Year

Type:

Drilling Machine

Material:

Metal

Power Supply:

380V/50Hz

Drilling Depth:

0-50mm

Model:

Double Side

Packaging Details:

Wrap plastic film

Supply Ability:

30 set per month

Product Description

Special Valve Machining Machine - Two Side Porous Drill Valve Body - Valve Drilling Machine

Vicord Double-Sided Multi-Hole Drilling Machine for Valve/Flange/Tee

Dual-sided drilling - Simultaneous processing reduces cycle time by 50%
Multi-spindle configuration - Drills 4-16 holes per side in single setup
High-precision - ±0.02mm hole positioning accuracy
CNC/PLC control - Automated operation with preset programs

Technical Specifications:
• Max workpiece size: 600×400×300mm
• Spindle speed: 200-3000rpm
• Drill capacity: Φ3-25mm

Machine Applications:

Automotive: Engine blocks, transmission housings
Valves/Pipes: Flanges, tees, valve bodies
General engineering: Hydraulic components, machinery parts

Advantages:
50% faster than single-side machining
Eliminates secondary clamping errors
Customizable for special materials (stainless/cast iron)

Project	YC II Z200HT	YC II Z300HT	YC II Z400HT	YC II Z600HT
Technical specifications	∅295	∅410	∅525	∅770
	600	800	800	1000
	200	200	300	300
	340	450	450	450
	moshi2#	moshi2#/moshi3#	moshi2#/moshi3#	moshi2#/moshi3#
Processing accuracy	≤0.5≤0.5	≤0.6≤0.6	≤0.8≤0.8	≤1≤1
Processing accuracy	12.5	12.5	12.5	12.5
Spindle drive	2 level	2 level	2 level
	225/286	197/223	159/231	11KW motor
	YE2-132M–6–5.5KW	YE2-132M–6–5.5KW	YE2-132M–6–7.5KW	YE2-180L–8–11KW
control system (optional)	PLC
Feed form (optional)	Hydraulic drive
Machine shape	2800X1000X1500	3200X1200X1700	3300X1200X1700	3400X1500X2000
Machine weight (kg)	1800	2200	3000

Processed Products

Special Valve Machining Machine - Two Side Porous Drill Valve Body - Valve Drilling Machine 0


Special Valve Machining Machine - Two Side Porous Drill Valve Body - Valve Drilling Machine 1
