Two Sides Horizontal Porous Drilling Machine For Valve Body/Pump Body/Auto Parts

Brand Name:	Vicord
Model Number:	YC II Z200/300/400/600HT
MOQ:	1
Price:	Negotiable
Payment Terms:	L/C,T/T
Supply Ability:	30 set per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Maximum Drilling Center Distance (mm):

295-770

Maximum Machining Length(mm):

600-1000 Mm

Minimum Machining Length(mm):

200-300 Mm

Surface Roughness:

12.5

Spindle Motor Range (r/min):

225/286

Control System:

PLC

Warranty:

1 Year

Type:

Drilling Machine

Material:

Metal

Power Supply:

380V/50Hz

Drilling Depth:

0-50mm

Model:

Double Side

Packaging Details:

Wrap plastic film

Supply Ability:

30 set per month

Product Description

Special Valve Machining Machine - Two Side Porous Drill Valve Body - Valve Drilling Machine

We are involved in Supplying Two Sides Horizontal Porous Drilling Machine for Valve Body/Pump Body/Auto Parts in China,
Horizontal porous drilling machine includes horizontal porous combination drilling machine, hydraulic automatic horizontal porous drilling machine, mechanical semi-automatic horizontal porous drilling hydraulic drilling machine.
Hydraulic automatic horizontal porous drilling machine is driven by hydraulic pressure as power, can realize stepless speed regulation of borehole, to improve drilling efficiency. Combination of porous power heads can be designed according to workpiece.

Advantage

Dual-sided drilling - Simultaneous processing reduces cycle time by 50%
Multi-spindle configuration - Drills 4-12 holes per side in single setup
CNC/PLC control - Automated operation with preset programs

Technical Specifications:
• Max workpiece size: 600×400×300mm(can be customized)
• Spindle speed: 200-3000rpm
• Drill capacity: Φ3-25mm

Machine Applications:

Automotive: Engine blocks, transmission housings
Valves/Pipes: Flanges, tees, valve bodies flange ,pipe fittings , flange fittings
General engineering: Hydraulic components, machinery parts

Project	YC II Z200HT	YC II Z300HT	YC II Z400HT	YC II Z600HT
Technical specifications	∅295	∅410	∅525	∅770
	600	800	800	1000
	200	200	300	300
	340	450	450	450
	moshi2#	moshi2#/moshi3#	moshi2#/moshi3#	moshi2#/moshi3#
Processing accuracy	≤0.5≤0.5	≤0.6≤0.6	≤0.8≤0.8	≤1≤1
Processing accuracy	12.5	12.5	12.5	12.5
Spindle drive	2 level	2 level	2 level
	225/286	197/223	159/231	11KW motor
	YE2-132M–6–5.5KW	YE2-132M–6–5.5KW	YE2-132M–6–7.5KW	YE2-180L–8–11KW
control system (optional)	PLC
Feed form (optional)	Hydraulic drive
Machine shape	2800X1000X1500	3200X1200X1700	3300X1200X1700	3400X1500X2000
Machine weight (kg)	1800	2200	3000

Processed Products

Two Sides Horizontal Porous Drilling Machine For Valve Body/Pump Body/Auto Parts 0


Two Sides Horizontal Porous Drilling Machine For Valve Body/Pump Body/Auto Parts 1
